Belintra - UBeFlex Stationary Racking/Storage System - Type W

The Belintra UBeFlex® W-Type Stationary Racking System is a highly hygienic and flexible modular storage solution designed for demanding healthcare environments, including Central Sterile Supply Departments (CSSD/SPD), operating theatres, hospital pharmacies and medical cold storage areas.

The W-Type (Wide) configuration uses standard 600 × 400 mm ISO dimensions, positioning baskets and modules with the 600 mm side facing the user and 400 mm deep. This provides a wider front-facing storage area and easier visibility and access to stored products.

Manufactured from anodised aluminium and high-quality synthetic materials, UBeFlex® is designed for durability, stability and easy cleaning. Its modular, tool-free construction allows components to be configured or adjusted as storage requirements change. The system is suitable for both sterile and non-sterile healthcare environments and can also be configured for pass-through access.

Important

Stationary Posts, Connection Sets, Click Runners, Brackets and Shelves are sold separately. These components are essential to build a complete single or add-on unit.

Each Single Unit Requires:

• 2 × W-Type Stationary Posts
• 1 × Connection Set
• 1 × Set of Brackets for Shelf – 900 mm or 1200 mm
• For a 900 mm unit: 3 × 300 mm W-Type shelves
• For a 1200 mm unit: 4 × 300 mm W-Type shelves
• 1 × Click Runners per basket

Each Add-On Unit Requires:

• 1 × W-Type Stationary Post
• 1 × Connection Set
• 1 × Set of Brackets for Shelf – 900 mm or 1200 mm
• For a 900 mm unit: 3 × 300 mm W-Type shelves
• For a 1200 mm unit: 4 × 300 mm W-Type shelves
• 1 × Click Runners per basket

The W-Type synthetic shelf is 300 mm wide × 400 mm deep, with wider shelf configurations created by combining individual shelf sections.
